The HafcoVac EXLR is a 55-gallon stainless steel industrial vacuum powered entirely by compressed air — no electricity, no motors, no moving parts. The single Venturi air-driven system creates suction without electrical components, making it certified safe for hazardous, combustible, and classified environments. Stainless steel construction resists water, acids, alkaline solutions, and chlorine exposure.
Air Supply, Capacity, and Construction
Power source: Compressed air — no electricity required
Drive system: Single Venturi (EXLR air-driven system)
Capacity: 55-gallon stainless steel drum
Construction: Industrial-grade stainless steel
Chemical resistance: Water, acids, alkaline solutions, chlorine
Temperature resistance: Fire and heat resistant
Explosion-proof: Certified for hazardous and combustible environments
Setup: Ships fully assembled — connect to compressed air supply and operate
Classified and Hazardous Environments
In locations where flammable dust, vapor, or combustible materials are present, electric vacuum motors create ignition risk through electrical arcing. An air-powered Venturi vacuum eliminates this risk entirely — there are no electrical components, no sparks, and no heat-generating motors. The HafcoVac EXLR is certified for use in classified hazardous environments where NEC Class I, II, or III standards apply. The stainless steel drum and body are compatible with the grounding and bonding requirements common in chemical plants, petrochemical facilities, pharmaceutical production, and grain handling operations. At 55 gallons, the drum handles large-volume material recovery with fewer dump cycles, reducing the number of times personnel need to interrupt work to empty the vessel.
Venturi Operation and What Ships
The single EXLR Venturi uses compressed air flow to create a low-pressure zone at the vacuum inlet — no impeller or motor is involved. Suction performance depends on your compressed air supply: verify that your facility's air supply meets the CFM and PSI requirements listed in the HafcoVac spec sheet for the EXLR system. The unit ships fully assembled and ready to connect. For higher CFM requirements or longer hose runs, consider the Dual EXLR configuration (30-gallon or 55-gallon options available separately).
Specification
Value
Model
EXLR (Single Venturi)
Capacity
55 gallons
Power Source
Compressed air (no electricity)
Construction
Industrial-grade stainless steel
Explosion-Proof Rating
Certified for hazardous and combustible environments
Chemical Resistance
Water, acid, alkaline, chlorine
Temperature Resistance
Fire and heat resistant
Setup
Fully assembled — connect to compressed air supply
What compressed air supply is required for the HafcoVac EXLR 55-gallon?
The EXLR uses a single Venturi system driven by compressed air. The required CFM and PSI from your air supply is specified in the HafcoVac EXLR technical data sheet. Contact HafcoVac or our team to confirm the air supply specifications before purchasing.
Is the HafcoVac EXLR certified for NEC hazardous locations?
The EXLR is explosion-proof certified for hazardous and combustible environments. For specific NEC classification (Class I, II, or III; Division 1 or 2) verification, request the HafcoVac certification documentation to confirm it meets your facility's compliance requirements.
Does the 55-gallon EXLR have any moving parts?
No. The Venturi air system creates suction without any motors, impellers, or mechanical moving parts. This eliminates the primary maintenance items that fail on electric vacuums — motor brushes, capacitors, and bearings — and removes electrical ignition risk entirely.
What is the difference between the 55-gallon EXLR and the 55-gallon Dual EXLR?
The EXLR uses a single Venturi and requires a lower CFM air supply. The Dual EXLR uses two Venturi units in parallel, requiring 185 CFM of compressed air but producing stronger suction for larger debris, longer hose runs, or higher-volume cleanup. Choose single EXLR for moderate demands; Dual EXLR for higher throughput requirements.
Can the stainless steel EXLR handle liquid pickup?
Yes. The stainless steel drum and Venturi system can recover both dry debris and liquids. For chemically reactive liquids, verify that the specific chemical is compatible with 304 or 316 stainless steel (depending on the drum specification) before use.
