Ebac CD425 10140BR-US Refrigerant Dehumidifier 220V – 285 PPD, 1750 CFM, 353 lbs
1/4
Ebac CD425 10140BR-US Refrigerant Dehumidifier 220V – 285 PPD, 1750 CFM, 353 lbs
Ebac CD425 10140BR-US Refrigerant Dehumidifier 220V – 285 PPD, 1750 CFM, 353 lbs
Ebac CD425 10140BR-US Refrigerant Dehumidifier 220V – 285 PPD, 1750 CFM, 353 lbs
Ebac CD425 10140BR-US Refrigerant Dehumidifier 220V – 285 PPD, 1750 CFM, 353 lbs

Ebac CD425 10140BR-US Refrigerant Dehumidifier 220V – 285 PPD, 1750 CFM, 353 lbs

Brand: EbacSKU: CD425Only 3 left – order soon
$10,676.00
FREE SHIPPING – You save $200+ on freight

Ships from US manufacturer with factory warranty

Ach Direct DebitAmazon American Express Apple Pay Diners ClubDiscoverGoogle Pay MastercardPayPalShop Pay USDC Visa
Authorized RetailerFactory-authorized dealer with genuine products
Manufacturer's WarrantyFull manufacturer warranty included
30-Day ReturnsHassle-free returns within 30 days
Lowest Price GuaranteedWe match any competitor's price
Ordering 3+ units? Call for volume pricing – (978) 295-7538
Order before 5:00 PM EST for same-day dispatch. Estimated delivery:

Need help choosing? Talk to an expert

(978) 295-7538

Ebac CD425-D HVAC Dehumidifier – Model 10140BR-US (220V, 3-Phase, Gravity Drain)

The Ebac CD425-D (10140BR-US) is the 220V, gravity-drain configuration of the CD425-D refrigerant HVAC dehumidifier. Drawing 16A at 220V for 3.6 kW, it delivers 285 PPD extraction and 1,750 CFM airflow, reverse-cycle defrost to 33°F, and digital humidistat control — all identical to the other CD425-D variants. Without an internal pump, condensate drains by gravity, which requires a floor drain directly accessible below the unit. This is the simplest CD425-D configuration: fewer mechanical components, lower acquisition cost, and no pump maintenance.

CD425-D 10140BR-US – Key Specifications and Features

  • Model: 10140BR-US (CD425-D, 220V 3-phase, gravity drain)
  • Extraction rate: 285 PPD
  • Airflow: 1,750 CFM
  • Electrical: 220V, 3-phase, 60 Hz, 16A, 3.6 kW
  • Defrost system: reverse-cycle defrost
  • Operating temperature: 33°F to 95°F
  • Effective volume: 52,970 ft³
  • Condensate removal: gravity drain (no internal pump)
  • Control: digital adjustable humidistat
  • Construction: welded steel chassis, baked epoxy and vinyl coating
  • Dimensions: 43" W × 19" D × 47" H
  • Weight: 353 lbs

Where the CD425-D 10140BR-US Performs

International and older North American industrial facilities with 220V 3-phase distribution and proper floor drain infrastructure use the 10140BR-US as the most straightforward CD425-D installation. Warehouses designed with trench drains running beneath equipment positions and facilities where building codes specify gravity drainage for condensate systems are the primary environments. The absence of a pump means one fewer electrical component and eliminates condensate pump service intervals, which matters in facilities with infrequent maintenance schedules.

Selecting the Right CD425-D Configuration

220V with pump (10147BR-US) suits sites with 220V power and no nearby floor drain. 220V gravity drain (10140BR-US) suits sites with 220V power and accessible floor drainage. 460V with pump (10149BR-US) suits sites with 460V power and no nearby drain. 460V gravity drain (10148BR-US) suits sites with 460V power and accessible floor drainage. All configurations deliver 285 PPD at 1,750 CFM.

Model 10140BR-US
Extraction Rate 285 PPD
Airflow 1,750 CFM
Electrical 220V, 3-phase, 16A, 3.6 kW
Min Operating Temp 33°F
Max Operating Temp 95°F
Effective Volume 52,970 ft³
Condensate Gravity drain
Dimensions 43" W × 19" D × 47" H
Weight 353 lbs



Documents

CD425 Wiring Diagram (PDF)

CD425 Wiring Schematic (PDF)

Spec Sheet

Manual

Product Warranty Information

"1 Year"
Product Image
Added to cart
Ebac CD425 10140BR-US Refrigerant Dehumidifier 220V – 285 PPD, 1750 CFM, 353 lbsEbac CD425 10140BR-US Refrigerant Dehumidifier 220V – 285...
View Cart

Frequently Asked Questions

What is the difference between the CD425-D 10146BR-US and 10147BR-US?
Both are 220V 3-phase CD425-D units with 285 PPD, 1,750 CFM, 16A, 3.6 kW. The 10146BR-US uses gravity drain (no pump); the 10147BR-US includes an internal condensate pump. Choose gravity drain where floor drains are directly accessible; choose the pump version where drainage requires lift.
What electrical supply does the CD425-D 10146BR-US require?
The 10146BR-US requires 220V, 3-phase, 60 Hz at 16A (3.6 kW). Circuit protection should be sized at 20A or larger per electrical code.
How does gravity drain work on the CD425-D 10146BR-US?
Gravity drain means condensate collected during dehumidification flows downward through a drain line to a floor drain or condensate pan. No pump is included — the installation requires a floor drain or collection point directly below and accessible via gravity from the unit's condensate outlet.
What is the extraction rate of the CD425-D 10146BR-US?
The 10146BR-US extracts 285 PPD using a refrigerant compressor with reverse-cycle defrost. Operating range is 33°F to 95°F — identical to all four CD425-D variants.
Does the CD425-D 10146BR-US work below 33°F?
No. The CD425-D refrigerant compressor requires a minimum ambient temperature of 33°F. For sub-freezing environments, specify Ebac's DD700, DD900, or DD1200 desiccant units, which operate to -4°F.
How does the 10146BR-US compare to the 10148BR-US?
Both are gravity-drain CD425-D models with identical 285 PPD, 1,750 CFM, and 3.6 kW performance. The 10146BR-US runs on 220V 3-phase at 16A; the 10148BR-US runs on 460V 3-phase at 8A. Select based on available site voltage.
