The NaceCare DP 620 (part number 8025116) is the 22-inch version of NaceCare's cylindrical Hydrowasher platform — the same counter-rotating cylindrical brush technology as the 14-inch DP 420, scaled up to a 22-inch path with a 1,500W brush motor for 6,000 square feet per hour on hard floors and mixed-surface environments. At 82 lbs, 57 lb brush pressure, 750 RPM, and 64 dB(A), this machine delivers precision cylindrical brush agitation in larger commercial spaces where the DP 420's 14-inch path would require too many passes.
DP 620 22-Inch Cylindrical Brush Performance vs. the DP 420
22" cleaning path / 6,000 sq ft/hr: covers 50% more floor per hour than the 14-inch DP 420 (4,000 sq ft/hr) at the same cleaning speed; appropriate for larger restrooms, corridors, and commercial kitchens where the 14-inch machine would require excessive passes.
1,500W brush motor: 50% more motor power than the DP 420 (1,000W), driving the wider cylindrical brush at consistent 750 RPM across the full 22-inch path without speed reduction under load.
Counter-rotating cylindrical brushes, 57 lb pressure: same cleaning mechanism as the DP 420 — brushes converge and lift soil from grout, textured surfaces, rubber, and carpet without the surface-profile limitations of flat disc pads.
Offset brush and drive unit: brush assembly extends to the machine edge for wall-to-baseboard cleaning without a separate edge pass.
64 dB(A) noise level: same quiet operation as the DP 420 despite the wider path and higher motor power; suitable for occupied commercial environments.
2-gal solution / 2-gal recovery tanks: larger recovery tank than the DP 420 (1 gal), consistent with the higher water flow handling from a wider 22-inch brush system.
Commercial Facility Applications and DP 420 vs. DP 620 Selection
The DP 420 (14") is the right choice for single restrooms, small break rooms, escalator treads, and confined areas where the 22-inch machine cannot maneuver. The DP 620 (22") is the right choice for larger restroom facilities, commercial kitchen floors, wide corridors, and open retail areas where the 14-inch machine would be inefficiently slow. Both machines are appropriate for mixed-surface facilities that require the same machine to handle grouted tile, rubber, textured concrete, and carpet cleaning with brush changes between surface types.
DP 620 Operation and Multi-Surface Brush Options
The trigger-controlled solution dispensing makes DP 620 operation straightforward — fill tanks, position, and pull the trigger. Brush selection is the primary performance variable: black brushes for aggressive hard floor scrubbing, grey for all-purpose use on standard commercial floors, and yellow for carpet interim maintenance. The offset brush design cleans right to baseboards on each pass, reducing the time-consuming hand-cleaning that flat disc machines require along floor edges.
This product comes with a full manufacturer's warranty. All warranty claims are handled directly by the manufacturer.
For specific warranty details, please contact us at +1 (978) 295-7538 or email info@uscleaningtools.com
B2B & Tax-Exempt Purchases
We supply contractors, restoration companies, property managers, schools, government agencies, and other tax-exempt organizations.
How to place a tax-exempt order:
Write to us through our Contact Us page or email info@uscleaningtools.com and attach your valid tax exemption certificate (state resale or exemption certificate).
We verify your certificate and mark your account tax-exempt — usually within one business day.
Place your order and sales tax will not be charged.
For volume pricing or purchase orders, call +1 (978) 295-7538.
Shipping & Returns
Free shipping on most brands for orders over $300, delivered to the lower 48 states. Any brand-specific freight rate is shown at checkout before you pay.
Processing & delivery: in-stock orders are processed within 1–2 business days and typically deliver in 5–7 business days. Tracking is emailed within 24 hours of shipment. Built-to-order and backordered equipment shows its lead time on this page.
Freight deliveries: inspect your equipment on arrival and note any damage on the delivery receipt. Items damaged in transit or defective on arrival are fully covered at no cost to you.
Cancellations: cancel any time before your order ships for a full 100% refund.
30-day returns: return unused equipment in its original packaging within 30 days of delivery. Change-of-mind returns are subject to a restocking fee. To start a return, email info@uscleaningtools.com or call +1 (978) 295-7538.
Frequently bought with the NaceCare DP 620 8025116 Hydrowasher – 22", 750 RPM, 1500W, 64 dB, 6,000 Sq Ft/Hr
Added to your order — shipped together.
Frequently Asked Questions
How does the DP 620 differ from the DP 420?
The DP 620 has a 22-inch cleaning path and 1,500W motor, versus the DP 420's 14-inch path and 1,000W motor. The DP 620 covers 6,000 sq ft/hr compared to the DP 420's 4,000 sq ft/hr. Choose the DP 620 for larger restrooms, commercial kitchens, and wide corridors where the 14-inch machine would require too many passes.
What brush speed does the NaceCare DP 620 operate at?
The DP 620 operates its counter-rotating cylindrical brushes at 750 RPM with 57 lbs of brush pressure. The 1,500W motor maintains this speed across the full 22-inch brush path without slowing under load on heavily soiled or textured floor surfaces.
Can the DP 620 clean carpet and hard floors with the same machine?
Yes. By switching brush heads — black for hard floor scrubbing, grey for general use, yellow for carpet — the DP 620 adapts between hard floor scrubbing and carpet interim maintenance cleaning. This eliminates the need for a separate carpet maintenance machine in facilities with mixed flooring types.
Does the DP 620 clean right up to walls and baseboards?
Yes. The offset brush and drive unit design extends the cylindrical brushes to the machine edge, allowing cleaning right up to baseboards without leaving an uncleaned strip along walls. This eliminates the separate edge-cleaning step required after most disc scrubbers.
How loud is the NaceCare DP 620?
The DP 620 operates at 64 dB(A), the same as the smaller DP 420 despite having a wider path and more powerful motor. 64 dB is approximately normal conversation volume, suitable for cleaning during occupied hours in hospitals, schools, hotels, and retail stores.
What types of floors can the DP 620 clean?
The DP 620 cleans grouted tile, rubber flooring, textured concrete, hardwood, ceramic, and carpet (with appropriate brush heads). The cylindrical brush design reaches into surface texture and grout joints that flat disc scrubbers ride over without agitating, making it effective on surfaces that disc machines clean poorly.
